Grandstream Networks UCM630X Series User Manual

P a g e | 176
UCM630X Series User Manual
Version 1.0.11.10
CFB Time
Condition
Select time condition for Call Forward Busy. The available time conditions ‘All’, ‘Office
Time’, ‘Out of Office Time’, ‘Holiday’, ‘Out of Holiday’, ‘Out of Office Time or Holiday’,
‘Office Time and Out of Holiday’, ‘Specific Time’, ‘Out of Specific Time’, ‘Out of Specific
Time or Holiday’, ‘Specific Time and Out of Holiday’.
Notes:
• “Specific” has higher priority to “Office Times” if there is a conflict in terms of time
period.
• Specific time can be configured under the Specific Time section. Scroll down the
add Time Condition for a specific time.
• Office Time and Holiday could be configured on page System Settings→Time
Settings→Office Time/Holiday page.
Do Not Disturb
If Do Not Disturb is enabled, all incoming calls will be dropped. All call forward settings
will be ignored.
DND Time
Condition
Select time condition for Do Not Disturb. The available time conditions are “Office
Time”, “Out of Office Time”, “Holiday”, “Out of Holiday”, “Out of Office Time or Holiday”,
and “Specific”.
Notes:
• “Specific” has higher priority to “Office Times” if there is a conflict in terms of time
period.
• Specific time can be configured under the Specific Time section. Scroll down the
add Time Condition for a specific time.
Office Time and Holiday could be configured on page System Settings→Time
Settings→Office Time/Holiday page.
