Outbound Prepend

Configure the prepend digits to be added at before dialing the outside number.

The number with prepended digits will be used to match the outbound route. ‘-’

is the connection character which will be ignored.

Delay Before Callback

Configure the number of seconds to be delayed before calling back the user.

Destination

Configure the destination which the callback will direct the caller to. Two

destinations are available:

• IVR

• DISA

The caller can then enter the desired number to dial out via UCM630X trunk.
