there are no restrictions. Configuration reads have no restrictions; however, only one internal
configuration access (PLB
or
PCI side) may be serviced at a time.
Table 17-7. Collision Resolution
PLB
Non-postable
Access
Type
PLB
Read
from
PCI
PLB
Postable
Write
to
PCI
Write
to
PCI
PCI
Write
to
PLB
Rearbitrate PLB master No conflict Rearbitrate PLB master
(reads flush writes)
PCI Read
from
PLB
Rearbitrate PLB master
No conflict
Rearbitrate PLB master
17.5
PCI
Bridge Configuration Registers
The PCI bridge has two sets of configuration registers for configuring the bridge, handling errors, and
reporting status.
Local configuration registers control PLB functions, and are accessed only from the
PLB. The
PCI configuration registers control PCI functions, and can be accessed from the PLB and
the
PCI. In addition, the mechanism used to access the bridge configuration registers may also be
used to configure other devices on the
PCI bus.
17.5.1
PCI
Bridge Register Summary
Table 17-8 provides a summary of all of the PCI bridge registers. The registers are discussed in detail
in
the following sections. See Chapter
8,
"Reset and Initialization," for register reset values.
Table 17-8. Directly Accessed MMIO Registers
Register
Address
Access
,Description
Page
PCILO_PMMOLA
OxEF400000 RIW PMM 0
Local Address
17-21
PCILO_PMMOMA
OxEF400004
RIW
PMM 0
Mask/Attribute 17-25
PCILO_PMMOPCILA
OxEF400008
RIW
PMM 0 PCI Low Address
17-22
PCILO_PMMOPCIHA
OxEF40000C
RIW
PMM 0 PCI High Address
17-23
PCILO_PMM1 LA
OxEF400010 RIW PMM 1 Local Address 17-23
PCILO_PMM1 MA
OxEF400014
RIW
PMM 1 Mask/Attribute 17-21
PCILO_PMM1 PCILA
OxEF400018
RIW
PMM
1 PCI Low Address 17-24
PCILO_PMM1 PCIHA
OxEF40001C
RIW
PMM 1 PCI High Address 17-25
PCILO_PMM2LA
OxEF400020
RIW
PMM 2 Local Address 17-25
PCILO_PMM2MA
OxEF400024
RIW PMM
2 Mask/Attribute
17-25
PCILO_PMM2PCILA
OxEF400028
RIW
PMM 2 PCI Low Address 17-26
PCILO_PMM2PCIHA
OxEF40002C
RIW
PMM 2 PCI High Address
17-27
PCILO_PTM1 MS
OxEF400030
RIW
PTM 1 Memory Size/Attribute 17-27
PCILO_PTM1LA
OxEF400034
RIW
PTM
1 Local Address 17-27
PCILO_PTM2MS
OxEF400038
RIW
PTM
2 Memory Size/Attribute 17-28
PCILO_PTM2LA
OxEF40003C
RIW
PTM 2 Local Address 17-28
Preliminary
~CI
Interface
17-19
