dcbz Data Cache Block Set to Zero
Fills a line in the cache with zeros and marks the line as modified.
If the line is not currently in the cache (and the address is marked as cachable and
non-write-through), the
line is established, filled with zeros, and marked as modified
without
actually filling the line from external memory. If the line is marked as either
non-cachable or write-through, an alignment exception results.
dccci Data Cache Congruence Class Invalidate
Invalidates
a congruence class (both cache ways).
This is a privileged instruction.
dcread
Data Cache Read
Reads either a data cache tag entry
or a data word from a data cache line, typically
for debugging. Bits in CCRD control instruction behavior (see "Cache Control and
Debugging Features" on page 4-11).
This is a
privileged instruction.
4.4 Cache Control and Debugging Features
Registers and instructions are provided to control cache operation and help debug cache problems.
For ICU debug, the icread instruction and the Instruction Cache Debug Data Register (ICDBDR) are
provided. See
"ICU Debugging" on page 4-14 for more information. For DCU debug, the dcread
instruction is provided. See "DCU Debugging". on page 4-15 for more information.
CCRD
controls the behavior of the icread and the dcread instructions.
LWL SWOA IPP
LBDE PFNC FWOA
CWS
o
5
Figure 4-2. Core Configuration Register 0 (CCRO)
0:5
Reserved
6
LWL Load Word as Line
o The DCU performs load misses or non-
cachable loads as words, halfwords,
or
bytes, as requested
1 For
load misses or non-cachable loads,
the DCU moves eight words (including
the target word) into the line buffer
Preliminary Cache Operations
4-11
