IBM PowerPC 405GP User Manual

Part IV PPC405GP External Interfaces
Chapter 15 SDRAM Controller
Chapter 16 External Bus Controller
Chapter 17 PCI Interface
Chapter 18 Direct Memory Access Controller
Chapter 19 Ethernet Media Access Controller
Chapter 20 Memory Access Layer
Chapter
21 Serial Port Operations
Chapter 22
IIC Bus Interface
Chapter 23 GPIO Operations
Part V Reference
Chapter 24
Instruction Set
Chapter 25 Register Summary
Chapter 26
Signal Summary
This book contains the
following appendixes:
Appendix A
Instruction Summary
Appendix B
Instructions by Category
Appendix
C Code Optimization and Instruction Timings
To help readers find material in these chapters, the book contains:
Contents,
on page v.
Figures, on page xxix.
Tables, on page xli.
Index,
on page X-1.
Conventions
The following is a list of notational conventions frequently used in this manual.
ActiveLow
n
Oxn
Obn
/\
v
+
x
An overbar indicates an active-low signal.
A decimal number
A
hexadecimal number
A binary number
Assignment
AND
logical operator
NOT logical operator
OR logical operator
Exclusive-OR (XOR) logical operator
Twos complement addition
Twos complement subtraction, unary minus
Multiplication
xlviii
PPC405GP User's Manual Preliminary
