Configure System Information
150
M4300 Series and M4300-96X Fully Managed Switches User Manual
• Use All to display all physical ports and LAGs.
10. Use one of the following methods to select an interface:
• Use the Go To Interface
field by entering the interface in unit/slot/port format and
click the Go button. The entry corresponding to the specified interface, is selected.
• Use Interface to select the interface for which data is to be displayed or configured.
11. In the Downstream Interface field, specify whether the interface belongs to the group’
s
downstream list.
An interface that is defined as an upstream interface cannot be defined as a downstream
interface in the same link state group. The default value is False.
• Select
False to delete an interface from the downstream list of the specified group.
• Select True
to add an interface to the downstream list of the specified group.
12. In the Upstream Interface field, specify whether the interface belongs to the group’s
upstream list.
An interface that is defined as an upstream interface cannot be defined as a downstream
interface in the same link state group. The default value is False.
• Select
False to delete an interface from the upstream list of the specified group.
• Select True
to add an interface to the upstream list of the specified group.
13. Click the Apply button.
Your settings are saved.
14. Click the Update button to refresh the page with the latest information on the switch.
The following table describes the Link Dependency Interface Configuration nonconfigurable
information that displays on the page.
The following table describes the Link Dependency Group Statistic nonconfigurable
information that displays on the page.
Table 52. Link Dependency Interface Configuration Nonconfigurable Field
Field Description
Link Status Indicates whether the link for the corresponding interface is up or down.
Table 53. Link Dependency Group Statistic
Field Description
Group ID The Group ID for which data is displayed. The range is 1 to 16.
Link Action The action to be performed on downstream interfaces when all the
interfaces in the upstream list go down.
Group State The current state of the group.
Group Transitions Indicates the number of group transitions.
Last Transition Time Indicates the time of the last group transitions.
