Getting Started
25
M4300 Series and M4300-96X Fully Managed Switches User Manual
For example, if a switch with unit number 1 includes an APM402XL port card in slot 9, port 1
on the port card is connected to four individual port cards, and port 2 on the port card is
connected to another single 40G port, the port numbering is as follows: 1/9/1, 1/9/2, 1/9/3,
1/9/4, and 1/9/5.
For the APM402XL port card, the ports on the port cards in the slots are numbered as
described in the following table. (In the interface convention examples in the table, the switch
is designated as unit number 1.)
For the APM402XL port card, the ports in the port cards in the slots are numbered as
described in the following table.
Table 5. Port numbering for the 40G ports on the APM402XL port card
Slot
Number
Slot
Location
Port Port
Numbers
for 10G
Port
Numbers
for 40G
Interface Convention
1 Upper row 1 1, 2, 3, 4 1 For 10G: 1/1/1, 1/1/2, 1/1/3, and 1/1/4. For 40G: 1/1/1.
2 5, 6, 7, 8 5 For 10G: 1/1/5, 1/1/6, 1/1/7, and 1/1/8. For 40G: 1/1/5.
2 Upper row 1 1, 2, 3, 4 1 For 10G: 1/2/1, 1/2/2, 1/2/3, and 1/2/4. For 40G: 1/2/1.
2 5, 6, 7, 8 5 For 10G: 1/2/5, 1/2/6, 1/2/7, and 1/2/8. For 40G: 1/2/5.
3 Upper row 1 1, 2, 3, 4 1 For 10G: 1/3/1, 1/3/2, 1/3/3, and 1/3/4. For 40G: 1/3/1.
2 5, 6, 7, 8 5 For 10G: 1/3/5, 1/3/6, 1/3/7, and 1/3/8. For 40G: 1/3/5.
4 Upper row 1 1, 2, 3, 4 1 For 10G: 1/4/1, 1/4/2, 1/4/3, and 1/4/4. For 40G: 1/4/1.
2 5, 6, 7, 8 5 For 10G: 1/4/5, 1/4/6, 1/4/7, and 1/4/8. For 40G: 1/4/5.
5 Upper row 1 1, 2, 3, 4 1 For 10G: 1/5/1, 1/5/2, 1/5/3, and 1/5/4. For 40G: 1/5/1.
2 5, 6, 7, 8 5 For 10G: 1/5/5, 1/5/6, 1/5/7, and 1/5/8. For 40G: 1/5/5.
6 Upper row 1 1, 2, 3, 4 1 For 10G: 1/6/1, 1/6/2, 1/6/3, and 1/6/4. For 40G: 1/6/1.
2 5, 6, 7, 8 5 For 10G: 1/6/5, 1/6/6, 1/6/7, and 1/6/8. For 40G: 1/6/5.
7 Lower row 1 1, 2, 3, 4 1 For 10G: 1/7/1, 1/7/2, 1/7/3, and 1/71/4. For 40G: 1/7/1.
2 5, 6, 7, 8 5 For 10G: 1/7/5, 1/7/6, 1/7/7, and 1/7/8. For 40G: 1/7/5.
8 Lower row 1 1, 2, 3, 4 1 For 10G: 1/8/1, 1/8/2, 1/8/3, and 1/8/4. For 40G: 1/8/1.
2 5, 6, 7, 8 5 For 10G: 1/8/5, 1/8/6, 1/8/7, and 1/8/8. For 40G: 1/8/5.
9 Lower row 1 1, 2, 3, 4 1 For 10G: 1/9/1, 1/9/2, 1/9/3, and 1/9/4. For 40G: 1/9/1.
2 5, 6, 7, 8 5 For 10G: 1/9/5, 1/9/6, 1/9/7, and 1/9/8. For 40G: 1/9/5.
10 Lower row 1 1, 2, 3, 4 1 For 10G: 1/10/1, 1/10/2, 1/10/3, and 1/10/4.
For 40G: 1/10/1.
2 5, 6, 7, 8 5 For 10G: 1/10/5, 1/10/6, 1/10/7, and 1/10/8.
For 40G: 1/10/5.
