Manage Device Security
548
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. In the Group ID list, select the group ID.
7. Use Port List to add the ports you selected to this private group.
The port list displays when at least one group is configured.
8. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 200. Private Group Membership
Field Description
Group Name The name for the private group that you selected. It can be up to 24
non-blank characters long.
Group Mode The mode of the private group that you selected. The modes are as
follows:
• community
• isolated
When in isolated mode, the member port in the group cannot forward
its egress traf
fic to any other members in the same group. By default,
the mode is community mode. Each member port can forward traf
fic to
other members in the same group, but not to members in other groups.
