NETGEAR M4300 User Manual

Monitor the System
628
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. Use a button at the bottom of the page to perform one of the following actions:
• To clear all the EAP counters for all ports on the switch, select the check box in the
row heading and click
the Clear button. Clicking the button resets all statistics for all
ports to default values.
• To clear the counters for a specific port, select the check box associated with the port
and click
the Clear button.
• To refresh the page with the latest information on the switch, click the Update button.
The following table describes the EAP statistics displayed on the page.
Table 219. EAP Statistics
Field Description
Port Selects the port to be displayed. When the selection is changed, a page update
occurs causing all fields to be updated for the newly selected port. All physical
interfaces are valid.
P
AE Capabilities This displays the PAE capabilities of the selected port.
EAPOL Frames Received This displays the number of valid EAPOL frames of any type that were received
by this authenticator
.
EAPOL Frames
Transmitted This displays the number of EAPOL frames of any type that were transmitted by
this authenticator.
EAPOL Start Frames
Received
This displays the number of EAPOL start frames that were received by this
authenticator.
EAPOL Logof
f Frames
Received
This displays the number of EAPOL logoff frames that were received by this
authenticator.
EAPOL Last Frame V
ersion This displays the protocol version number carried in the most recently received
EAPOL frame.
EAPOL Last Frame Source This displays the source MAC address carried in the most recently received
EAPOL frame.
EAPOL Invalid Frames
Received
This displays the number of EAPOL frames that were received by this
authenticator in which the frame type is not recognized.
EAPOL Length Error Frames
Received
This displays the number of EAPOL frames that were received by this
authenticator in which the frame type is not recognized.
EAP Response/ID Frames
Received
This displays the number of EAP response/identity frames that were received by
this authenticator
.

NETGEAR M4300 Specifications

General

Model	M4300
Form Factor	Rack-Mountable
Layer	Layer 3
Stackable	Yes
Managed	Yes
Memory	Varies by model
Flash Memory	Varies by model
Warranty	Lifetime
Ports	Varies by model (24 or 48 ports)
PoE	Available on some models
Port Speed	10/100/1000 Mbps, 10Gbps on uplinks
Forwarding Rate	Varies by model
Jumbo Frame Support	Yes
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0° to 50° C (32° to 122° F)
Power Supply	Internal
Uplink Ports	Varies by model (SFP/SFP+ or 10G SFP+)
