C613-50055-01 REV A Command Reference for x230 Series Edge Switches 529
AlliedWare Plusâ„¢ Operating System - Version 5.4.5-0.x
POWER OVER ETHERNET COMMANDS
SHOW
POWER-INLINE INTERFACE DETAIL
Related
Commands
show power-inline
show power-inline interface
Current power
consumption:
The power consumption for the PoE port when this command
was entered. Note that the power consumption may have
changed since the command was entered and the power is
displayed.
Powered
device class:
The class of the connected PD if connected, and if power is being
supplied to the PD from the PSE.
See the PoE Feature Overview and Configuration Guide for
further information about power classes.
Power
allocated:
The power in milliwatts (mW) allocated for the PoE port.
Additionally, note the following as displayed per PoE port:
• [U] if the power limit for a port was user configured (with the
power-inline max command).
• [L] if the power limit for a port was supplied by LLDP.
• [C] if the power limit for a port was supplied by the PD class.
Detection of
legacy
devices is
[Enabled|Disabled]
The status of legacy PoE detection on the PoE port, as configured
for the PoE port with the power-inline allow-legacy command.
Powered
pairs:
[Data|Spare]
The IEEE 802.3af and IEEE 802.3at standards allow for either data
or spare twisted pairs to be used to transfer power to a PD.
The powered pairs status for each port. AlliedWare Plusâ„¢ PoE
switches implement IEEE 802.3af and IEEE 802.3at Endpoint PSE
Alternative A (Data).
Table 14-4: Parameters in show power-inline interface detail command output
Parameter Description
