UCM630X Series User Manual
Version 1.0.11.10
trunk. If enabled, the other stations can press the line button to join the call.
The default setting is Yes.
The hold option specifies hold permissions for this trunk. If set to “Open”, any station
can place this trunk on hold and any other station is allowed to retrieve the call. If set
to “Private”, only the station that places the call on hold can retrieve the call.
The default setting is Yes.
If enabled, a polarity reversal will be marked as received when an outgoing call is
answered by the remote party. For some countries, a polarity reversal is used for
signaling the disconnection of a phone line and the call will be considered as “Hangup”
on a polarity reversal. The default setting is “No”.
When the FXO port answers the call, FXS may send a Polarity Reversal. If this interval
is shorter than the value of “Polarity on Answer Delay”, the Polarity Reversal will be
ignored. Otherwise, the FXO will On-hook to disconnect the call. The default setting
is 600ms.
Current
Disconnect
Threshold (ms)
This is the periodic time (in ms) that the UCM630X will use to check on a voltage
drop in the line. The default setting is 200. The valid range is 50 to 3000.
Configure the ring timeout (in ms). Trunk (FXO) devices must have a timeout to
determine if there was a Hangup before the line is answered. This value can be used
to configure how long it takes before the UCM630X considers a non-ringing line with
Hangup activity. The default setting is 8000.
Configure the RX gain for the receiving channel of the analog FXO port. The valid
range is from -13.5 (dB) to + 12.0 (dB). The default setting is 0.
Configure the TX gain for the transmitting channel of the analog FXO port. The valid
range is from -13.5 (dB) to + 12.0 (dB). The default setting is 0.
Configure to enable CallerID detection.
The default setting is “Yes”.
Select the Caller ID scheme for this trunk.
• Bellcore/Telcordia.
