Send PAI Header
If enabled, the SIP INVITE message sent to the trunk will contain PAI (P-Asserted-
Identity) header including configured PAI Header. The default setting is “No”.
Note: “Send PPI Header” and “Send PAI Header” cannot be enabled at the same
time. Only one of the two headers can be contained in the SIP INVITE message.
PAI Header
If “Send PAI Header” is enabled and “PAI Header” is configured as “123456” for
instance, the PAI header in the SIP message sent from the UCM will contain
“123456”. If “Send PAI Header” is enabled and “PAI Header” is configured as
“empty”, the PAI header in the SIP message sent from the UCM will contain the
original CID.
Note:
“Send PAI Header” needs to be enabled to use this feature
Send Anonymous
If checked, the "From" header in the outgoing INVITE message will be set to
anonymous.
DOD As From Name
If enabled and "From User" is configured, the INVITE's From header will contain
the DOD number.
Passthrough PAI
Header
If checked and the option "Send PAI Header" is not checked, the PAI header will
be passthrough from one side to the other side.
Send PANI Header
If checked, the INVITE and REGISTER sent to the trunk will contain the P-Access-
Network-Info header.
Access Network Info
The access network information is in the P-Access-Network-Info header.
Send Anonymous
If checked, the "From" header in the outgoing INVITE message will be set to
anonymous.
Outbound Proxy
Support
Select to enable outbound proxy in this trunk.
The default setting is "No".
Outbound Proxy
When outbound proxy support is enabled, enter the IP address or URL of the
outbound proxy.
Remove OBP from
Route
It is used to set if the phone system will remove outbound proxy URI from the route
header. If is set to “Yes”, it will remove the route header from SIP requests. The
default setting is “No”.
