17.5.3.3 PCI Vendor ID Register (PCICO_VENDID)

PCICO_ VENDID identifies the manufacturer

a PCI device. This register contains

Ox1

014

(index

OxOO

= Ox14, index

Ox01

= Ox10) at reset. This vendor ID is assigned for all IBM PCI devices.

The

local CPU (PLB master) can write a different value to this register.

Figure 17-25.

PCI

Vendor 10 Register (PCICO_VENDlD)

115:0

Vendor

17.5.3.4 PCI Device ID Register (PCICO_DEVID)

PCICO_DEVID identifies the PCI device. This value is Ox0156 (index Ox03 = Ox01, index Ox02 = Ox56)

reset.

The

local CPU (PLB master) can write a different value to this register.

\15

Figure 17-26. PCI Device 10 Register (PCICO_DEVID)

115:0

1 PCI Device

17.5.3.5 PCI Command Register (PCICO_CMD)

PCICO_CMD controls the operation of the PCI bridge on the PCI bus. Figure 17-27 describes the bits.

Preliminary

PCI Interface

17-31
