716 Command Reference for x230 Series Edge Switches C613-50055-01 REV A
AlliedWare Plus™ Operating System - Version 5.4.5-0.x
IPV4 SOFTWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST EXTENDED (NAMED)
Mode Global Configuration
Default Any traffic controlled by a software ACL that does not explicitly match a filter is
denied.
Usage Use this command when configuring access-list for filtering IP software packets. To
enable backwards compatibility you can either create access-lists from within this
command, or you can enter access-list followed by only the number. This latter
<ip-protocol>
(cont.)
Protocol Number Protocol Description [RFC Reference]
33 Datagram Congestion Control Protocol
[RFC4340]
48 DSR (Dynamic Source Routing Protocol)
[RFC4728]
50 ESP (Encap Security Payload) [RFC2406]
51 AH (Authentication Header) [RFC2402]
54 NARP (NBMA Address Resolution Protocol)
[RFC1735]
88 EIGRP (Enhanced Interior Gateway Routing
Protocol)
89 OSPFIGP [RFC1583]
97 Ethernet-within-IP Encapsulation / RFC3378
98 Encapsulation Header / RFC1241
108 IP Payload Compression Protocol / RFC2393
112 Virtual Router Redundancy Protocol /
RFC3768
134 RSVP-E2E-IGNORE / RFC3175
135 Mobility Header / RFC3775
136 UDPLite / RFC3828
137 MPLS-in-IP / RFC4023
138 MANET Protocols / RFC-ietf-manet-iana-
07.txt
139-252 Unassigned / IANA
253 Use for experimentation and testing /
RFC3692
254 Use for experimentation and testing /
RFC3692
255 Reserved / IANA
Table 22-4: Parameters in the access-list extended (named) command -
proto|ip|any (cont.)
Parameter Description
