Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 4-1
4
Port Configuration
This chapter describes the Port Configuration set of commands and how to use them.
4.1 PORT CONFIGURATION SUMMARY
The Matrix E1 has fixed front panel ports at the bottom of the chassis and either one or three
optional Ethernet expansion module slot(s) at the top of the chassis.
Matrix E1 fixed front panels provide the following port configurations:
• The 1H582-25 fixed front panel provides 24 RJ45 10/100 Mbps ports.
• The 1H582-51 fixed front panel provides 48 RJ45 10/100 Mbps ports.
• The 1G582-09 fixed front panel provides 6 RJ45 10/100/1000 Mbps ports.
• The 1G587-09 fixed front panel provides 6 Small Form Factor Pluggable (SFP) 1-Gigabit fiber
optic ports.
Depending on the Ethernet expansion module(s) installed, each slot provides up to 16 ports via Fast
Ethernet RJ45 connectors, or Gigabit Ethernet via fiber optic connections using GBICs.
4.1.1 Port Assignment Scheme
The expansion module and fixed front panel port numbering scheme used when configuring Matrix
E1 ports is shown in Figure 4-1. Ports 1 through 24, or 1 through 48, are RJ45 10/100 Ethernet
connections, and are designated as 0 for being fixed ports on the front panel. In this numbering
scheme, front panel port 8 is expressed as 0.8 in the CLI syntax.
NOTE: Illustrations and most of the examples in this guide are based on the Matrix E1
1H582-51. Configuration and CLI output for the Matrix E1 1H582-25 and 1G58x-09 may
be different. Unless noted, procedures and performance features are similar for both
models.
