Security Configuration Command Set
Configuring MAC Locking
14-48 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
This example shows how to display MAC locking information for the end stations connected to Fast
Ethernet front panel port 8:
Table 14-6 provides an explanation of the command output.
14.3.4.3 set maclock enable
Use this command to enable MAC locking on one or more ports. When enabled and configured for
a specific MAC address and port string, this locks a port so that only one end station address is
allowed to participate in frame relay.
set maclock enable [port-string]
Matrix>show maclock stations fe.0.8
Number of stations found: 3
Port Number MAC address Status State
------------ ----------------- --------------- --------------
fe.0.8 00-20-78-06-0e-a0 active first learned
fe.0.8 00-44-55-44-55-21 active static
fe.0.8 00-a0-39-00-0c-7b active first learned
Table 14-6 show maclock stations Output Details
Output What It Displays...
Port Number Port designation. For a detailed description of possible
port-string values, refer to Section 4.1.2.
MAC address MAC address of the end station(s) locked to the port.
Status Whether the end stations are active or inactive.
State Whether the end station locked to the port is a first learned,
first arrival or static connection.
NOTE: MAC locking is disabled by default at device startup. Configuring one or more
ports for MAC locking requires globally enabling it on the device and then enabling it on
the desired ports as described in Section 14.3.4.5.
