Security Configuration Command Set
Configuring MAC Locking
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 14-59
14.3.4.15set maclock autostatic passthroughmac
Use this command to enable a received multicast destination MAC address to be scoped to VLAN
egress lists other than that of the VLAN of which it is a member.
set autostatic passthroughmac mac-address
Syntax Description
Command Defaults
None.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to assign MAC address 01:00:5e:00:00:05 as the autostatic MAC pass
through address:
NOTE: For this command to work properly, both the public ingress and egress VLANs
must be configured for autostatic MAC locking and described in Section 14.3.4.13, and
the pass through MAC address must be a multicast address. Improper use of this
command may result in connectivity issues.
mac-address Specifies a MAC address.
Matrix>set maclock autostatic psssthrough mac 01:00:5e:00:00:05
