Connecting to a Console Port for Local Management
Connecting to a Modem
2-6 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Another solution, if the modem cannot be configured to completely suppress traffic to the console
port at start-up, would be to configure the E1 lockout retry count to a higher value or disable it
altogether. You would do this using the set system lockout attempts command as described in
Section 3.2.1.8.
Figure 2-3 Connecting to a Modem
1 RJ45 Modem Port 3 RJ45-to-DB25 Modem Adapter 5 RJ45 Console Port
2 Modem 4 UTP Cable with RJ45 Connectors
