Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Bridge Parameters
6-24 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Syntax Description
Command Defaults
If bridge mode is disabled, a port-string is required to reset all ports. For
information on using the set spantree bridgehellomode command, refer to
Section 6.2.1.19.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to reset the bridge hello time to 2 seconds:
6.2.1.23 set spantree maxage
Use this command to set the bridge maximum aging time. This is the maximum time (in seconds)
a device can wait without receiving a configuration message (bridge “hello”) before attempting to
reconfigure. All device ports (except for designated ports) should receive configuration messages
at regular intervals. Any port that ages out STP information provided in the last configuration
message becomes the designated port for the attached LAN. If it is a root port, a new root port is
selected from among the device ports attached to the network.
set spantree maxage agingtime
port-string (Optional) Resets the hello time for specific port(s).
NOTE: Port-string cannot be specified if bridge
hello mode is enabled. For information on using the
set spantree bridgehellomode command, refer to
Section 6.2.1.19.
Matrix>clear spantree hello
