Enterasys 1G58x-09 - Optional Ethernet Expansion Modules

Port Configuration Summary
Port Assignment Scheme
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 4-3
Figure 4-2 Optional Ethernet Expansion Modules
Table 4-1 Ethernet Expansion Module Interface Types and Port Numbering
Ethernet expansion module Interface Type Port Numbering
1H-16TX Fast Ethernet
10/100BASE-TX
Sixteen fixed RJ45 ports
| 1 | 3 | 5 | 7 | 9 | 11 | 13 | 15 |
| 2 | 4 | 6 | 8 | 10 | 12 | 14 | 16 |
1G-2TX Fast Ethernet
1000BASE-TX
Two fixed RJ45 ports
| 1 | 2 |
1G-2GBIC Gigabit
1000BASE-SX/LX
Two port slots for optional GBICs
(GBICs have 1 SC connector)
| 1 | 2 |
37552_27
1G-2TX
1
1
1H-16TX
1G-2GBIC
1G-2GBIC
1
1G-2MGBIC
1
1
1H-8FX
