Process Overview: Routing Protocol Configuration
Configuring OSPF
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 13-61
Example
This example shows how to display OSPF virtual links information:
Table 13-6 provides an explanation of the command output.
13.1.2.29clear ip ospf process
Use this command to reset the OSPF process. This will require adjacencies to be reestablished and
routes to be reconverged.
clear ip ospf process process-id
Matrix>Router#show ip ospf virtual-links
Virtual Link to router 5.5.5.1, is UP
Transit area 0.0.0.2,via interface Vlan 7, Cost of using 10
Transmit Delay is 1 sec(s), State POINT_TO_POINT
Timer intervals configured:
Hello 10, Dead 40, Wait 40, Retransmit 5
Adjacency State FULL
Table 13-6 show ip ospf virtual links Output Details
Output What It Displays...
Virtual Link ID of the virtual link neighbor, and the virtual link status,
which is up or down.
Transit area ID of the transit area through which the virtual link is
configured.
via interface Router’s interface into the transit area.
Cost of using OSPF cost of routing through the virtual link.
Transit Delay Time (in seconds) added to the LSA (Link State
Advertisement) age field when the LSA is transmitted
through the virtual link.
State Interface state assigned to a virtual link, which is
point-to-point.
Timer intervals
configured
Timer intervals configured for the virtual link, including
Hello, Dead, Wait, and Retransmit intervals.
Adjacency State State of adjacency between this router and the virtual link
neighbor of this router.
