Logging and Network Management Command Set
Managing Switch Network Addresses
11-46 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
11.2.3.13set port stopaging
Use this command to enable or disable stopping the aging process of MAC address entries on one
or more ports. When enabled, this will prevent addresses from aging out due to inactivity on
configured ports. Addresses will, however, update properly if moved from port to port.
set port stopaging port-string [enable | disable]
Syntax Description
Command Defaults
If disable is not specified, stopaging will be enabled.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to enable the stop aging function on Fast Ethernet front panel ports 1
through 8:
NOTE: This command must be configured in groups of eight ports for Fast Ethernet
ports. Port string variables that are a subset of eight will be rounded up to include all
eight ports. For example, if you enable stop aging on ports fe.0.1-4, ports fe.0.1-8 will
also be enabled. If you enable it on ports fe.0.4-12, this spans two groups of eight, so
groups fe.0.1-8, and fe.0.9-16 will be enabled. The show command will reflect the actual
setting. For a detailed description of designating port-string values, refer to
Section 4.1.2.
port-string Specifies the port(s) on which to enable or disable the stop
aging function. For a detailed description of possible
port-string values, refer to Section 4.1.2.
enable | disable (Optional) Enables or disables the stop aging function.
Matrix>set port stopaging fe.0.1-8
