IP Configuration Command Set
Reviewing and Saving the Routing Configuration
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 12-11
12.2.2.2 write
Use this command to save or delete the router running configuration, or to display it to output
devices.
write [erase | file [filename config_file] | terminal]
Table 12-2 show running-config Output Details
Output What It Displays...
Router id Router ID (IP address) used by the OSPF protocol for path
selection. Unless configured by using the router id
command as described in Section 13.1.2.3, this will default
to the lowest IP address of interfaces configured for routing
on the device.
interface vlan VLANs configured for IP routing and their IP addresses. At
least two VLAN interfaces must be configured for IP routing
to operate the device in router mode. For details on how to
do this, refer to Section 3.3.2.
router rip RIP routing protocol is enabled, For details on configuring
RIP, refer to Section 13.1.1.
network IP address of a directly connected network that RIP will
advertise to its neighboring routers. For details on adding or
removing a RIP network, refer to Section 13.1.1.2.
NOTE: The write file command must be executed in order to save the router
configuration to NVRAM. If this command is not executed, router configuration changes
will not be saved upon reboot.
