Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Port Parameters
6-42 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
6.2.2.7 clear spantree portpri
Use this command to reset the bridge priority of a Spanning Tree port to the default value of 128.
clear spantree portpri [port-string] [sid]
Syntax Description
Command Defaults
• If port-string is not specified, bridge priority will be reset for all ports.
• If sid is not specified, bridge priority will be reset on all SIDs.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to reset the priority of Fast Ethernet front panel port 3 to 128:
port-string (Optional) Resets the priority for specific port(s). For a
detailed description of possible port-string values, refer
to Section 4.1.2.
sid (Optional) Resets the port priority for a specific SID.
Matrix>clear spantree portpri fe.0.3
