Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Bridge Parameters
6-6 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
6.2.1.1 show spantree stats
Use this command to display Spanning Tree information for one or more ports or Spanning Trees.
show spantree stats [sid sid] [port port-string]
Syntax Description
Command Defaults
• If port-string is not specified, Spanning Tree information for the device will be
displayed.
• If sid is not specified, information for Spanning Tree 0 will be displayed.
Command Type
Switch command.
Command Mode
Read-Only.
sid sid (Optional) Displays Spanning Tree information for a
specific Spanning Tree.
port port-string (Optional) Displays Spanning Tree information for specific
port(s). For a detailed description of possible port-string
values, refer to Section 4.1.2.
