Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Bridge Parameters
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 6-7
Example
This example shows how to display Spanning Tree information for Fast Ethernet front panel port 1:
Table 6-1 provides an explanation of command output.
Matrix>show spantree stats port fe.0.1
Spanning tree - enabled
Spanning tree instance - 0
Designated Root MacAddr - 00:00:1d:11:71:00
Designated Root Priority - 32768
Designated Root Cost - 0
Designated Root Port - 0
Root Max Age - 20 sec
Root Hello Time - 2 sec
Root Hold Time - 1 sec
Root Forward Delay - 15 sec
Bridge ID Mac Address - 00:00:1d:11:71:00
Bridge ID Priority - 32768
Bridge Max Age - 20 sec
Bridge Hello Time - 2 sec
Bridge Forward Delay - 15 sec
Topology Change Count - 6
Max Hops - 20
SID Port State Role Cost Priority
-----------------------------------------------------------
0 fe.0.1 blocking disabled 100 128
Table 6-1 show spantree stats Output Details
Output What It Displays...
Spanning tree Whether the Spanning Tree Protocol is enabled or
disabled. Default state of enabled can be changed
using the set spantree command
(Section 6.2.1.2).
Spanning tree instance Spanning Tree ID. Set using the set spantree msti
command (Section 6.2.1.7).
Designated Root MacAddr MAC address of the designated Spanning Tree
root bridge.
Designated Root Priority Priority of the designated root bridge.
