Logging and Network Management Command Set
Configuring Node Aliases
11-70 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
11.2.5.3 set nodealias
Use this command to enable or disable a node alias agent on one or more ports. Upon packet
reception, node aliases are dynamically assigned to ports enabled with an alias agent, which is the
default setting on Matrix E1 Series devices. Node aliases cannot be statically created, but can be
deleted using the clear node alias command as described in Section 11.2.5.5
.
set nodealias {enable | disable} port-string
Table 11-8 show nodealias config Output Details
Output What It Displays...
Total Control
Entries
Total aliases learned.
Active Entries Number of Total Control Entries that are active (not marked
for deletion).
Purge Time Last time the node alias table was cleared.
State Node alias is ready to learn new entries.
Allocated Entries Number of entries that have been allocated to all the ports.
This is the total of the Max Entries column.
Available Entries Maximum node alias buffers available.
Port Number Port designation.
Max Entries Maximum number of alias entries configured for this port.
Set using the set nodealias maxentries command
(Section 11.2.5.4).
Used Entries Number of alias entries (out of the maximum amount
configured) already used by this port.
Status Whether or not a node alias agent is enabled (default) or
disabled on this port.
