Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Port Parameters
6-56 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Example
This example shows how to set the LAN attached to Fast Ethernet front panel port 3 as a
point-to-point segment:
6.2.2.27 clear spantree adminpoint
Use this command to resets the point-to-point admin status to “auto” on one or more ports.
clear spantree adminpoint [port-string]
Syntax Description
Command Defaults
If port-string is not specified, point-to-point status will be reset on all ports.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to reset the point-to-point status of the LAN segment attached to Fast
Ethernet front panel port 3 to auto:
Matrix>set spantree adminpoint fe.0.3 true
port-string (Optional) Resets point-to-point status on specific port(s).
For a detailed description of possible port-string values,
refer to Section 4.1.2.
Matrix>clear spantree adminpoint fe.0.3
