Port Configuration Command Set
Setting Speed and Duplex Mode
4-14 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
• set port speed (Section 4.3.3.2)
• show port duplex (Section 4.3.3.3)
• set port duplex (Section 4.3.3.4)
4.3.3.1 show port speed
Use this command to display the configured port speed used when the port’s auto-negotiation state
is disabled. Note that the configured speed may be different from the current assigned speed, if
auto-negotiation is enabled.
show port speed [port-string]
Syntax Description
Command Defaults
If a port string is not entered, configured port speed settings for all ports are
displayed.
Command Type
Switch command.
Command Mode
Read-Write.
port-string (Optional) Specifies the port(s) for which speed will be
displayed. For a detailed description of possible
port-string values, refer to Section 4.1.2.
