Port Configuration Command Set
Setting Port Auto-Negotiation and Advertised Ability
4-20 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
4.3.5 Setting Port Auto-Negotiation and Advertised Ability
Purpose
To determine whether auto-negotiation is enabled or disabled for the specific port and to set the
state, and to display or set a port’s advertised mode of operation.
During auto-negotiation and advertised ability, the port “tells” the device at the other end of the
segment what its capabilities and mode of operation are. If auto-negotiation is disabled, the port
reverts to the values specified by default speed, default duplex, and the port flow control commands.
In normal operation, with all capabilities enabled, advertised ability enables a port to “advertise”
that it has the ability to operate in any mode. The user may choose to configure a port so that only
a portion of its capabilities are advertised and the others are disabled.
Commands
The commands needed to configure auto-negotiation are listed below and described in the
associated section as shown.
• show port negotiation (Section 4.3.5.1)
• set port negotiation (Section 4.3.5.2)
• show port advertised ability (Section 4.3.5.3)
• set port advertised ability (Section 4.3.5.4)
NOTE: Advertised ability can be activated only on ports that have auto-negotiation
enabled.
