Port Priority and Classification Configuration Commands
Configuring Port Traffic Rate Limiting
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 9-37
Example
This example shows how to:
• globally enable rate limiting on the device,
• configure rate limiting on port priority 5 for Fast Ethernet front panel ports 3 through 7 to a
threshold of 20,000 bits per second,
• discard all frames, and enable rate limiting with these parameters on the specified ports:
9.3.6.3 clear port ratelimit
Use this command to reset rate limiting parameters back to default values for one or more priorities
on one or more ports.
clear port ratelimit port-string {priority}
Syntax Description
Command Defaults
None.
Command Type
Switch command.
Command Mode
Read-Write.
Matrix>set port ratelimit enable
Matrix>set port ratelimit fe.0.3-7 5 200000 discard enable
port-string Specifies a port on which to reset the rate limiting
threshold and other parameters. For a detailed
description of possible port-string values, refer to
Section 4.1.2.
priority Specifies the 802.1D port priority level associated with
the port-string on which to reset rate limiting. Valid
values are:
• 0 - 7, with 0 specifying the lowest priority, and
• all to reset the rate limiting threshold and other
parameters on all port priority levels associated with
the port-string.
