Process Overview: Routing Protocol Configuration
Configuring VRRP
13-78 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Syntax Description
Command Syntax of the “no” Form
The “no” form of this command disables the VRRP session:
no create vlan vlan_id vrid
Command Type
Router command.
Command Mode
Router configuration: Matrix>Router(config-router)#
Command Defaults
None.
Example
This example shows how to create a VRRP session on VLAN 1 with a VRID of 1:
13.1.5.3 address
Use this command to configure a virtual router IP address. If the virtual router IP address is the same
as the interface (VLAN) address owned by a VRRP router, then the router owning the address
becomes the master. The master sends an advertisement to all other VRRP routers declaring its
status and assumes responsibility for forwarding packets associated with its virtual router ID
(VRID). If the virtual router IP address is not owned by any of the VRRP routers, then the routers
compare their priorities and the higher priority owner becomes the master. If priority values are the
same, then the VRRP router with the higher IP address is selected master. For details on using the
priority command, refer to Section 13.1.5.4.
address vlan vlan_id vrid ip_address owner
vlan vlan_id Specifies the number of the VLAN on which to create a
VRRP session. This VLAN must be configured for IP
routing as described in Section 3.3.2.
vrid Specifies a unique Virtual Router ID (VRID) to associate
with the routing interface. Valid values are from 1 to 255.
Matrix>Router(config)#router vrrp
Matrix>Router(config-router)#create vlan 1 1
