Port Configuration Command Set
Setting Speed and Duplex Mode
4-16 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Example
This example shows how to set Fast Ethernet expansion module 3, port 9, to a port speed of 10
Mbps:
4.3.3.3 show port duplex
Use this command to display the configured port duplex setting (half or full) for one or more ports
used when the port’s auto-negotiation state is disabled. Note that the configured duplex setting may
be different from the current assigned setting, if auto-negotiation is enabled.
show port duplex [port-string]
Syntax Description
Command Defaults
If a port string is not entered, configured port duplex settings for all ports are
displayed.
Command Type
Switch command.
Command Mode
Read-Write.
Matrix>set port speed fe.3.9 10
port-string (Optional) Specifies the port(s) for which duplex
setting will be displayed. For a detailed description of
possible port-string values, refer to Section 4.1.2.
