Security Configuration Command Set
Configuring 802.1X Authentication
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 14-25
Examples
This example shows how to reset the 802.1X port control mode to auto on all ports:
This example shows how to reset reauthentication control to disabled on Fast Ethernet front panel
ports 1-3:
This example shows how to reset the 802.1X quiet period to 60 seconds on Fast Ethernet front panel
ports 1-3:
14.3.2.7 show eapol
Use this command to display EAPOL settings for one or more ports.
show eapol [port-string]
Syntax Description
Command Type
Switch command.
Command Mode
Read-Only.
Command Alternatives (v3.xx.xx and higher)
show dot1x (Section 14.3.2.1)
show dot1x auth-config authcontrolled-portcontrol (Section 14.3.2.4)
Matrix>clear dot1x auth-config authcontrolled-portcontrol
Matrix>clear dot1x auth-config reathenabled fe.0.1-3
Matrix>clear dot1x auth-config quietperiod fe.0.1-3
port-string (Optional) Displays EAPOL status for specific port(s). For
a detailed description of possible port-string values, refer to
Section 4.1.2.
