Port Configuration Command Set
Setting Port Mirroring
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 4-45
Command Mode
Read-Write.
Examples
This example shows how to set port mirroring with fe.0.4 as the source port and fe.0.11 as the target
port:
This example shows how to disable port mirroring:
4.3.9.3 clear port mirroring
Use this command to clear a mirroring association between ports.
clear port mirroring source_port
Syntax Description
Command Defaults
None.
Command Type
Switch command.
Command Mode
Read-Write.
Examples
This example shows how to clear port mirroring for source port fe.0.4:
Matrix>set port mirroring fe.0.4 fe.0.11
Matrix>set port mirroring disable
source_port Specifies the source port for the mirroring association to
be cleared. For a detailed description of possible
port-string values, refer to Section 4.1.2.
Matrix>clear port mirroring fe.0.4
