Enterasys 1G58x-09 User Manual

General Configuration Command Set
Setting Basic Device Properties
3-40 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
3.2.2.12 set system contact
Use this command to identify a contact person for the system.
set system contact [“contact_string”]
Syntax Description
Command Defaults
If contact_string is not specified, the contact name will be set to a blank string.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to set the system contact string:
3.2.2.13 show terminal
Use this command to display the number of columns and rows for the terminal connected to the
device’s console port. This information is used to control the output of the CLI itself.
show terminal
Syntax Description
None.
Command Defaults
None.
Command Type
Switch command.
contact_string (Optional) Specifies a text string that contains the name
of the person to contact for system administration. A
contact string containing a space in the text must be
enclosed in quotes as shown in the example below.
Matrix>set system contact “Joe Smith”

Enterasys 1G58x-09 Specifications

General

Redundant Power Supply	Optional
VLANs Supported	4094
Power Supply	100-240 VAC, 50-60 Hz
Weight	7.03 kg
Operating Temperature	0° to 40°C (32° to 104°F)
Storage Temperature	-20° to 70°C (-4° to 158°F)
Operating Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Ports	48 x 10/100/1000BASE-T
Jumbo Frame Support	9, 216 bytes
