Spanning Tree Configuration Command Set
Reviewing and Setting Spanning Tree Bridge Parameters
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 6-19
6.2.1.15 clear spantree mstcfgid
Use this command to reset the MST revision level to a default value of 0, and the configuration
name to a default string representing the bridge MAC address.
clear spantree mstcfgid
Syntax Description
None.
Command Defaults
None.
Command Type
Switch command.
Command Mode
Read-Write.
Example
This example shows how to reset the MST configuration identifier elements to default values:
6.2.1.16 set spantree priority
Use this command to set the bridge priority for one or more Spanning Trees. The device with the
highest priority becomes the Spanning Tree root device. If all devices have the same priority, the
device with the lowest MAC address will then become the root device.
set spantree priority bridge_priority [sid]
Syntax Description
Command Defaults
If sid is not specified, SID 0 will be assumed.
Matrix>clear spantree mstcfgid
bridge_priority Specifies the priority of the bridge. Valid values are
from 0 to 61440 (in increments of 4096), with 0
indicating high priority and 61440 low priority.
sid (Optional) Sets a priority for a specific Spanning
Tree.
