Port Configuration Command Set
Setting Port Mirroring
4-44 Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide
Ethernet front panel port 4, and Fast Ethernet front panel port 23 is mirroring traffic from Fast
Ethernet front panel port 19. Mirroring is currently disabled on the device:
4.3.9.2 set port mirroring
Use this command to enable, disable or configure mirroring between ports.
set port mirroring {disable | enable | source_port target_port}
Syntax Description
Command Defaults
None.
Command Type
Switch command.
Matrix>show port mirroring
Port Mirroring Status : Disabled
===============================
Source Port = fe.0.4
Target Port = fe.0.11
===============================
Source Port = fe.0.19
Target Port = fe.0.23
disable | enable Disables or enables port mirroring.
source_port Specifies the port designation for the source on which the
traffic will be monitored. For a detailed description of
possible port-string values, refer to Section 4.1.2.
target_port Specifies the port designation for the target that will
duplicate or “mirror” all the traffic on the monitored port.
For a detailed description of possible port-string values,
refer to Section 4.1.2.
NOTES: A given source port may only be mirrored to one target port. However, multiple
source ports may be mirrored to the same target port.
Only one port per port grouping can be designated as a source port. For more
information on port grouping designations, refer to Section 4.3.10.2.
A maximum of 12 source/target port pairs may be configured.
