Port Configuration Command Set
Configuring Link Aggregation
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 4-67
This example shows how to display LACP counters for all Fast Ethernet front panel ports:
This example shows how to display detailed LACP information for Fast Ethernet front panel port 1:
NOTES: State definitions, such as ActorAdminState and Partner AdminState, are
indicated with letter abbreviations. If the show port lacp command displays one or
more of the following letters, it means the state is true for the associated actor or partner
ports:
E = Expired; F = Defaulted; D = Distributing (tx enabled); C = Collecting (rx enabled);
S = Synchronized (attached to appropriate aggregator); A/i = Aggregable/individual
port; S/l = Short/Long LACP timeout; A/p = Active/Passive LACP.
For more information about these states, refer to set port lacp (Section 4.3.13.5) and
the IEEE 802.3 2002 specification.
Matrix>show port lacp counters fe.0.*
Port LACPTx LACPRx TLastRx MrkTx MrkRx LACPErr
------------------------------------------------------------------------
fe.0.1 23 20 22.84s 0 0 0
fe.0.2 7 4 12m 0 0 0
fe.0.3 0 0 n/a 0 0 0
Matrix>show port lacp detail fe.0.1
LACP Details for Port: fe.0.1
LAG ID:
[(0001,00001dfffefd,0001,00,0000),(0001,00e063a3e0ce,0001,00,0000)]
ActorOperKey: 1 AttachedAggID: lag.0.1
ActorAdminState: 5 ActorOperState: 0x3d --DCSAlA
PartnerAdminKey: 1 PartnerOperState: 0x3d --DCSAlA
PartnerOperKey: 1 PartnerOperSystemID: 00:e0:63:a3:e0:ce
RxState: Current MuxState: Distrib
MuxReason: SELECTED & PSync & PColl
