Port Priority and Classification Configuration Commands
Configuring Quality of Service (QoS)
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 9-15
Example, Mode 1
This example shows how to set hybrid Mode 1 and the transmission queues on Fast Ethernet front
panel ports 1 through 3. In this example the hybrid queues 0, 1, and 2 are being set to 30, 40, and
30 percent, respectively. Queue 3 will automatically use the 802.1p strict priority algorithm to
service the frames in Queue 3 first. Whenever there are no frames in Queue 3, frames in Queues 0,
1, and 2 will be serviced using the WRR algorithm:
Example, Mode 2
This example shows how to set hybrid Mode 2 and the transmission queues on the front panel Fast
Ethernet ports 1 through 3. In this example the hybrid queues 0 and 1 are being set to 20 and 80
percent, respectively. Queues 2 and 3 will automatically use the 802.1p strict priority algorithm to
service the frames in Queue 3 first, then Queue 2. Whenever there are no frames in Queues 3 and
2, frames in Queues 1 and 0 will be serviced using the WRR algorithm:
Matrix>set port qos hybrid 1 fe.0.1-3 30 40 30
Matrix>set port qos hybrid 2 fe.0.1-3 20 80
