Port Priority and Classification Configuration Commands
Classification Precedence Rules
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 9-29
NOTE: In Table 9-2, the following applies:
- Exact Match indicates a match of an explicitly defined address.
- Best Match indicates a match of an entire subnet, or range of addresses within a subnet.
Table 9-2 Classification Precedence
Classification Type (IP)
Precedence Level
(Default)
With 802.1Q
Priority Tag
Override
802.1Q frame tag received 1 12
Source MAC Address Best Match 2 1
Destination MAC Address Best Match 3 2
Source IP Address Exact Match 4 3
Source IP Address Best Match (Subnet) 5 4
Destination IP Address Exact Match 6 5
Destination IP Address Best Match (Subnet) 7 6
UDP / TCP Port Source 8 7
Classification Type (IP)
Precedence Level
(Default)
With 802.1Q
Priority Tag
Override
UDP / TCP Port Destination 9 8
IP ToS 10 9
IP Type 11 10
Protocol Type (Ether Type or DSAP/SSAP) 12 11
Receive Port 13 13
Classification Type (IPX)
Precedence Level
(Default)
With 802.1Q
Priority Tag
Override
802.1Q frame tag received 1 10
