Process Overview: Routing Protocol Configuration
Configuring OSPF
Matrix E1 Series (1G58x-09 and 1H582-xx) Configuration Guide 13-57
Example
This example shows how to display all OSPF related information for VLAN 1:
Table 13-4 provides an explanation of the command output.
Matrix>Router#show ip ospf interface vlan 1
Vlan 1 is UP
Internet Address 182.127.63.2 Mask 255.255.255.0,Area 0.0.0.0
Router ID 182.127.64.1,Network Type BROADCAST,Cost: 10
Transmit Delay is 1 sec,State BACKUPDR,Priority 1
Designated Router id 182.127.62.1, Interface addr 182.127.63.1
Backup Designated Router id 182.127.63.2,
Timer intervals configured, Hello 10,Dead 40,Wait 40,Retransmit 5
Neighbor Count is 1, Adjacent neighbor count is 1
Adjacent with neighbor 182.127.63.1 (Designated Router)
Table 13-4 show ip ospf interface Output Details
Output What It Displays...
Vlan Interface (VLAN) administrative status as up or down.
Internet Address IP address and mask assigned to this interface.
Router ID Router ID, which OSPF selects from IP addresses
configured on this router.
Network Type OSPF network type, for instance, broadcast.
Cost OSPF interface cost, which is either default, or assigned
with the ip ospf cost command. For details, refer to
Section 13.1.2.4.
Transmit Delay The number (in seconds) added to the LSA (Link State
Advertisement) age field.
State The interface state (versus the state between neighbors).
Valid values include BACKUPDR (Backup Designated
Router), and DR (Designated Router).
Priority The interface priority value, which is either default, or
assigned with the ip ospf priority command. For details,
refer to Section 13.1.2.5.
Designated Router
id
The router ID of the designated router on this subnet, if one
exists.
Interface addr IP address of the designated router on this interface.
