1-1
1 ACL Configuration Commands
z The command used to apply ACL rules to a VLAN is newly added, which is described in
packet-filter vlan.
z The command used to configure VLAN information for Layer 2 ACLs is newly added, which is
described in
rule (for Layer 2 ACLs).
ACL Configuration Commands
acl
Syntax
acl number acl-number [ match-order { auto | config } ]
undo acl { all | number acl-number }
View
System view
Parameters
all: Specifies to remove all access control lists (ACLs).
number acl-number: Specifies the number of an existing ACL or an ACL to be defined. ACL number
identifies the type of an ACL as follows.
z An ACL number in the range 2000 to 2999 identifies a basic ACL.
z An ACL number in the range 3000 to 3999 identifies an advanced ACL. Note that 3998 and 3999
cannot be configured because they are reserved for cluster management.
z An ACL number in the range 4000 to 4999 identifies a layer 2 ACL.
z An ACL number in the range 5000 to 5999 identifies a user-defined ACL.
match-order: Specifies the match order for ACL rules. Following two match orders exist.
z auto: Specifies to match ACL rules according to the depth-first rule.
z config: Specifies to match ACL rules in the order they are defined.
Note that the match-order keyword is not available to Layer 2 ACLs or user-defined ACLs. The match
order for layer 2 ACLs or user defined ACLs can only be config. For details about the two match orders,
refer to the relevant description in ACL Operation.
