1-23
processes internally, c0a80001 is the representation of 192.168.0.1 in hexadecimal, and 32 is the offset
of the source IP address field in an ARP packet that the switch processes internally.
[Sysname] acl number 5001
[Sysname-acl-user-5001] rule 1 deny 0806 ffff 16 c0a80001 ffffffff 32
[Sysname-acl-user-5001] quit
# Create user-defined ACL 5002 and define rule 1, specifying a 32-byte rule string, a rule mask of all Fs,
and an offset of 4. Then, apply the ACL to Ethernet 1/0/1.
[Sysname] acl number 5002
[Sysname-acl-user-5002] rule 1 deny
1234567890123456789012345678901234567890123456789012345678901234
ffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffff 4
[Sysname-acl-user-5002] quit
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] packet-filter inbound user-group 5002
In this example, the 32-byte rule string occupies eight offset units: 4 to 7 (Offset2), 8 to 11 (Offset3), 12
to 15 (Offset4), 16 to 19 (Offset5), 20 to 23 (Offset1), 24 to 27 (Offset7), 28 to 31 (Offset8), and 32 to 35
(Offset6), as shown in
Table 1-16. The rule can be assigned successfully.
# Create user-defined ACL 5003 and define rule 1, specifying a 32-byte rule string, a rule mask of all Fs,
and an offset of 24. Then, apply the ACL to Ethernet 1/0/2.
[Sysname] acl number 5003
[Sysname-acl-user-5003] rule 1 deny
1234567890123456789012345678901234567890123456789012345678901234
ffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffff 24
[Sysname-acl-user-5003] quit
[Sysname] interface Ethernet 1/0/2
[Sysname-Ethernet1/0/2] packet-filter inbound user-group 5003
Applying Acl 5003 rule 1 failed!
Reason: This type of ACL rule is not supported by the command which is attempting to use
the ACL!(Ethernet1/0/2)
In this example, the 32-byte rule string does not comply with the rule that a user-defined rule string can
contain up to eight mask offset units, and any two offset units cannot belong to the same offset group.
The ACL cannot be assigned.
After completing the above configuration, you can use the display acl command to view the
configuration information of the ACLs.
rule comment
Syntax
rule rule-id comment text
undo rule rule-id comment
View
Advanced ACL view, Layer 2 ACL view, user-defined ACL view
