1-3
--------------------------------------------------------------------------
1 S 0x8000,0000-0000-0000 0 1 NonS Ethernet1/0/2
2 M none 0 1 NonS Ethernet1/0/3
Table 1-2 Description on the fields of the display link-aggregation summary command
Field Description
Aggregation Group Type
Aggregation group type: D for dynamic, S for static, and
M for manual
Loadsharing Type
Load sharing type: Shar for load sharing and NonS for
non-load sharing
Actor ID Local device ID
AL ID Aggregation group ID
AL Type
Aggregation group type: D (dynamic), S (static), or M
(manual)
Partner ID
ID of the remote device, including the system priority and
system MAC address of the remote device
For a device belonging to an dynamic aggregation group
or static aggregation group, if no LACP packet is
received, the partner ID is displayed as 0x8000,
0000-0000-0000.
Select Ports Number of the selected ports
Unselect Ports Number of the unselected ports
Share Type
Load sharing type: Shar (load-sharing), or NonS
(non-load-sharing)
Master Port the smallest port number in an aggregation group
display link-aggregation verbose
Syntax
display link-aggregation verbose [ agg-id ]
View
Any view
Parameters
agg-id: Aggregation group ID, which ranges from 1 to 416 and must be the ID of an existing aggregation
group.
Description
Use the display link-aggregation verbose command to display the details about a specified
aggregation group or all aggregation groups.
Note that as ports in a manual link aggregation groups do not acquire the information about their peers
automatically, so the entries in the information about the peer ports displayed are all 0 instead of the
actual values.
