2-4
In Monitor Link, a monitor link group member can be a single port, a static link aggregation group, but
not a dynamic link aggregation group. The uplink port of a monitor link group can also be a smart link
group.
Do not use this command on member ports of a link aggregation group or a smart link group.
A port or a link aggregation group cannot serve as a member port for two smart link groups. On the
other hand, a port or a link aggregation group cannot serve as a member for a smart link group and a
monitor link group at the same time. However, a smart link group can serve as the uplink member port
of a monitor link group.
Examples
# Configure Ethernet 1/0/7 as a downlink port of the monitor link group
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] monitor-link group 1
[Sysname-mtlk-group1] port Ethernet 1/0/7 downlink
port monitor-link group
Syntax
port monitor-link group group-id{ uplink | downlink }
undo port monitor-link group group-id
View
Ethernet port view
Parameters
group-id: Monitor link group ID, ranging 1 to 24.
uplink: Specifies the port as the uplink port of the specified monitor link group
downlink: Specifies the port as the downlink port of the specified monitor link group
Description
Use the port monitor-link group command to configure the current port as a member of the specified
monitor link group.
Use the undo port monitor-link group command to remove the current port from the specified monitor
link group.
In Monitor Link, a monitor link group member can be a single port, a static link aggregation group, but
not a dynamic link aggregation group. Uplink port can also be a smart link group.
Do not use this command on member ports of a link aggregation group or a smart link group.
