2-1
2 Selective QinQ Configuration Commands
The selective QinQ feature is new to H3C S3600 Series Ethernet Switches.
Selective QinQ Configuration Commands
mac-address-mapping
Syntax
mac-address-mapping index source-vlan source-vlan-list destination-vlan dest-vlan-id
undo mac-address-mapping { index | all }
View
Ethernet port view
Parameters
index: Index of the inter-VLAN MAC address replicating configuration to be created or removed. This
argument is in the range 0 to 7.
source-vlan source-vlan-list: Specifies a list of the IDs of the VLANs, whose MAC address entries are
to be replicated to the MAC address table of the destination VLAN. You need to provide the
source-vlan-list argument in the form of { vlan-id [ to vlan-id ] }&<1-10>, where the VLAN ID after the to
keyword must be larger than or equal to the VLAN ID before the to keyword and &<1-10> means that
you can specify up to 10 VLANs/VLAN ranges for this argument.
dest-vlan-id: ID of the destination VLAN for replication, in the range 1 to 4094.
all: Removes all the inter-VLAN MAC address replicating configurations created on the current port.
Description
Use the mac-address-mapping command to configure the inter-VLAN MAC address replicating
feature for a port. This feature can replicate MAC address entries of the MAC address tables of
specified source VLANs to the MAC address table of the specified destination VLAN.
Use the undo mac-address-mapping command to disable this feature.
The inter-VLAN MAC address replicating feature is disabled on any port by default.
In a selective QinQ application, you can configure this feature to:
