4-4
Field Description
Elapsed time since last connection or
counters clear
Time passed since the information of the MSDP peer
was last cleared
Information about (Source,
Group)-based SA filtering policy
SA message filtering list information
z Import policy: Filter list for receiving SA messages
from the specified MSDP peer
z Export policy: Filter list for forwarding SA messages
from the specified MSDP peer
Information about SA-Requests
SA requests information
z Policy to accept SA-Request messages: Filtering rule
for receiving or forwarding SA messages from the
specified MSDP peer
z Sending SA-Requests status: Whether enabled to
send an SA request message to the designated
MSDP peer upon receiving a new Join message
Minimum TTL to forward SA with
encapsulated data
Minimum TTL of multicast packet encapsulated in SA
messages
SAs learned from this peer Number of cached SA messages
SA-cache maximum for the peer
Maximum number of SA messages from the specified
MSDP peer that can be cached
Input queue size Data size cached in the input queue
Output queue size Data size cached in the output queue
Counters for MSDP message
MSDP peer statistics:
z Count of RPF check failure: Number of SA messages
discarded due to RPF check failure
z Incoming/outgoing SA messages: Number of SA
messages received and sent
z Incoming/outgoing SA requests: Number of SA
request received and sent
z Incoming/outgoing SA responses: Number of SA
responses received and sent
z Incoming/outgoing data packets: Number of received
and sent SA messages encapsulated with multicast
data
display msdp sa-cache
Syntax
display msdp sa-cache [ group-address | source-address | as-number ] *
View
Any view
Parameters
group-address: Multicast group address. With this argument provided, the command displays the (S, G)
entries for the specified multicast group.
source-address: Multicast source address. With this argument provided, the command displays the (S,
G) entries for the specified multicast source.
