1-3
# Display the configurations of a remote source mirroring group on your S3600-EI series Ethernet
switch.
<Sysname> display mirroring-group 2
mirroring-group 2:
type: remote-source
status: active
mirroring port:
Ethernet1/0/1 inbound
reflector port: Ethernet1/0/2
remote-probe vlan: 10
# Display the configurations of a remote destination mirroring group on your S3600-EI series Ethernet
switch.
<Sysname> display mirroring-group 3
mirroring-group 3:
type: remote-destination
status: active
monitor port: Ethernet1/0/3
remote-probe vlan: 20
Table 1-2 Description on the fields of the display mirroring-group command
Field Description
mirroring-group
Port mirroring group number.
type
Port mirroring group type, which can be local, remote-source, or
remote-destination.
status Status of the port mirroring group, which can be active or inactive.
mirroring port
Source port in port mirroring. This field is available only for local
mirroring groups or remote source mirroring groups.
both/inbound/outbound
The direction of the mirrored packets, which can be one of the
following:
z both: means packets received on and sent from the mirroring port
are mirrored.
z Inbound: means packets received on the mirroring port are
mirrored.
z outbound: means packets sent from the mirroring port are
mirrored.
monitor port
Destination port. This field is available only for local mirroring groups
and remote destination mirroring groups.
reflector port
Reflector port. This field is available only for remote source mirroring
groups.
remote-probe vlan
Remote probe VLAN. This field is available only for remote
source/destination mirroring groups.
