YASKAWA DX100 Operator's Manual

3 Teaching
3.4 Modifying Steps
3-33
155507-1CD
RE-CSO-A037
DX100
3.4.1 Displaying the JOB CONTENT Window for Editing
3.4.1.1 Currently Called Up Job
1. Select {JOB} under the main menu.
2. Select {JOB}.
– The JOB CONTENT window appears.
3.4.1.2 Calling Up Other Jobs
1. Select {JOB} under the main menu.
2. Select {SELECT JOB}.
– The JOB LIST window appears.
3. Select the job name to be called.
NOTE
In any other than the teach mode, set the mode switch to
“TEACH”.
116 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
